LED surgical lights, single and combination lights CHROMOPHARE
®
E 778, E 668, E 558
Maintenance and inspection
92
Fig. 59 Screw for adjusting spring tension
7.
Pull out the LED module and disconnect the two plugs on
the LED control boards (see arrows).
8.
Connect the new LED module and put everything back
together.
