11
(*) Accessory.
(**) Weights calculated according to EN 15502.
(***) Values referred to atmospheric pressure at sea level.
(****) Up to 85°C if combined with the plate heat exchanger accessory.
(*****) To adjust the POWER MAX 110 and POWER MAX 150 models in Belgium, Switzerland and Hungary , please refer to the chapter
“Adjustments”.
Description
POWER MAX
U.M.
50 P
DEP
50 P 65 P 80 P 100 110 130 150
Emissions at max./min.
heat input, G25
CO
2 9 - 9 %
CO 72/3,2 80/3,2 92/7 93,5/7 84/8 94/8 92/6 95/7 ppm
Emissions at max./min.
power G30
CO
2 10,4-9,9 10,4-10,4 %
CO 132/6 137/6 138/10 142/10 148/11 159/11 172/13 180/15 ppm
Emissions at max./min.
power G31
CO
2 10,4-9,9 10,4-10,4 %
CO 136/8 141/8 142/11 147/11 153/12 163/12 177/14 185/16 ppm
Gas consumption (min-
max)
G20
0,95÷3,69 0,95÷4,76 1,43÷6,0 1,43÷7,24 2,06÷9,53 2,06÷10,29 2,37÷11,82 2,5÷13,91 mc/h
G30
0,73÷2,82 0,73÷3,64 1,09÷4,58 1,09÷5,53 1,57÷7,28 1,57÷7,86 1,81÷9,02 1,91÷10,62 kg/h
G31
0,71÷2,77 0,71÷3,57 1,07÷4,50 1,07÷5,43 1,54÷7,15 1,54÷7,72 1,78÷8,86 1,87÷10,43 kg/h
Flue gas temperature at max. power
and min. power 80-60°C
66,5/61 67,5/61 71/61 72/61 76/62 78/62 75/61 77/61 °C
Flue gas temperature at max. power
and min. power 50-30°C
44/32 45/32 45/33 46/33 47/35 49/35 45/33 48/35 °C
Flue gas mass ow rate (***) 0,015 0,02 0,025 0,03 0,04 0,046 0,05 0,06 Kg/s
Water-side resistance (∆T 20°C)
- - - - 160 210 350 510 mbar
Available useful discharge head (∆T
20°C)
420 250 490 390 - - - - mbar
Maximum working pressure 6 bar
Minimum supply pressure 0,7 bar
Maximum permitted temperature 100 °C
Lockout thermostat activation temper
-
ature
95 °C
Adjustment temperature (min / max) 30 / 80 (****) °C
Thermal module water content 5 5 15 15 17 17 23 25 l
Maximum condensation at 100% rated
heat output (50-30°C)
5,4
7,0 8,9 10,1 13,6 15,0 17,5 19,8 l/h
Power supply 230-50 V-Hz
Index of protection IPX4D IP
Consumption at full load Elmax 75 105 63 77 150 203 205 302 W
Consumption at part
load
Elmin 31 34 30 30 36 31 44 45 W
Electrical consumption
in standby mode
Psb 9 9 13 13 6 6 6 8 W
