BERG BC250 - COMPONENT LOCATIONS

6
Component Locations
Back view
Power supply line
Drain
1/2” FPT
Water inlet
3/8” FPT
Float Water pump
Top panel
Door
Evaporator (ice mold)
Bin full probe
Water tank
Water tank screw nut
Ice storage bin
Front bottom louver
Control panel cover
Adjustable foot
Ice scoop
Stability brackets
Power switch
Top view
