2 Installation
2.1 Parts Specification
The specification must be checked for complete-
ness.
The specification includes (Figure 2-1) comprises:
Q’ty Description Order number
1 WS5-5.281-00 64652810006
1 Plug shell Mains
connection
98050060642
1 Plug shell Motor
connection
98050060600
1 Plug shell for
signal interface 2
98050060642
1 Sub-D socket
(15 pole)
98050060558
1 Housing for
Sub-D socket
(15 pole)
98050060298
1 WS5-5 Technical
documentation
Doc. no.
211.347/DGB
230V
WS5-5
Figure 2-1 Parts specification
Installation
WS5-5 Doc. no. 211.347/DGB 03.96 2 – 1
