X13 Exploded Views May 2007
6) KNIFE, MOTOR & BEARING ASSEMBLY
1 Knife 3675-00277 8 Mount 3475-00963
2 Bolt 2175-00468 9 Belt 2375-00176
3 Washer 2275-00524 10 Screw 2175-02746
4 Knife Bearing Assy 4675-01140 11 O-Ring 2275-00554
5 Nut 2175-00469 12 O-Ring 2275-00530
6 Screw 2175-02744 13 Mount 3375-01269
7 Motor 4175-00686
