English
10
7 ELECTRICAL COMMISSIONING
7.1 Electrical configurations
During the commissioning, the actuator will correspond to one of the
two following configurations:
8 - Capacitor
7 - Switches board
6 - Torque limiter (except on
AQ5/10/15)
5 - Motor
4 Heating resistance
3 - Cams
2 - Terminal block
1 - Position indicator
Without Positioner
12 Capacitor
11 Handwheel
10 Heating resistance
9 Micro-switches
8 - Potentiometer
7 Mechanical stop
6 - Cams
5 - Plug (cable gland)
4 Power terminal block
3 - Push buttons
2 Command and signaling
terminal block
1 - Position indicator
With Positioner
The actuator and its components are wired to internal terminal
blocks.
