Berthoud MAXAIR 240 - TOREX NOZZLES

16 320.055-B MAXAIR
TOREX NOZZLES
IMPORTANT:
The totalowrateof the sprayer should be lessthan10%ofthe
maximumowrateofthepump.
Example:WithaGAMA82pump(owrate:80l/min),donotexceed
aowrateof70/72l/minforthesprayer.
- Openthenozzle:
 Toopenit,turnthenut(3)counterclockwise.
 Toclosethenozzle,turnthenut(3)clockwise.
- Flow rate adjustment:Usetheadjustingscrew(1).
- Wide spray:Obtainedby fully turningtheadjustingscrew (1)
clockwise.
- Average spray:Obtainedbyturningthescrew(1)halfaturncounter
clockwisefromthewidesprayposition.
- Narrow spray:Obtainedbyturningthescrew(1)acompleteturn
counterclockwisefromthewidesprayposition.
- Holdingtheowrate:Inordertoholdthesameowratewhenthe
nozzleisadjustedatthedesiredangle,turnthenut(2)againstthe
screw(1)totighten.
- Changingtheorientationofthenozzles:Tochangetheorientation
ofthenozzles,loosenthehexnut(4),orientatethenozzleandtighten
thenut.
Ø DISCS
PRESSURE
SPRAY
Litre /minute
Ø DISCS
PRESSURE
SPRAY
Litre /minute
Ø DISCS
PRESSURE
SPRAY
Litre /minute
Wide Narrow Wide Average Narrow Wide Average Narrow
6/10
10 0.54 0.56
12/10
10 1.54 2.08
20/10
10 2.30 4.06 4.65
15 0.66 0.68 15 1.99 2.52 15 3.02 5.20 5.76
20 0.76 0.78 20 2.38 2.92 20 3.68 6.24 6.75
25 0.86 0.88 25 2.76 3.26 25 4.28 7.20 7.68
30 0.94 0.96 30 3.08 3.57 30 4.86 8.04 8.50
35 1.02 1.04 35 3.35 3.86 35 5.43 8.82 9.30
40 1.08 1.10 40 3.58 4.13 40 5.96 9.52 10.08
45 1.13 1.14 45 3.70 4.38 45 6.46 10.12 10.80
50 1.17 1.18 50 3.80 4.61 50 6.95 10.63 11.50
8/10
10 0.76 1.02
15/10
10 2.04 2.58 3.16
25/10
10 3.20 5.50 6.70
15 1.00 1.24 15 2.68 3.32 3.92 15 4.10 6.80 8.00
20 1.22 1.46 20 3.28 4.01 4.65 20 4.90 8.00 9.20
25 1.44 1.66 25 3.84 4.64 5.30 25 5.70 9.00 10.40
30 1.64 1.84 30 4.34 5.21 5.90 30 6.40 10.00 11.60
35 1.82 2.00 35 4.80 5.73 6.42 35 7.00 11.00 12.80
40 2.00 2.14 40 5.20 6.16 6.88 40 7.60 12.00 14.00
45 2.16 2.26 45 5.51 6.52 7.24 45 8.20 13.00 15.00
50 2.30 2.35 50 5.76 6.80 7.53 50 8.80 14.00 16.00
10/10
10 0.93 1.44
18/10
10 2.24 3.34 4.20
30/10
10 3.80 6.00 7.70
15 1.20 1.78 15 2.92 4.14 5.12 15 4.60 7.50 10.00
20 1.46 2.06 20 3.46 4.84 5.90 20 5.40 9.00 12.00
25 1.69 2.32 25 4.12 5.48 6.60 25 6.10 10.40 14.00
30 1.92 2.56 30 4.66 6.06 7.22 30 6.70 11.80 15.50
35 2.13 2.78 35 5.18 6.64 7.80 35 7.30 13.00 17.00
40 2.33 2.99 40 5.67 7.16 8.36 40 7.90 14.00 18.50
45 2.52 3.19 45 6.12 7.67 8.92 45 8.50 15.00 20.00
50 2.71 3.38 50 6.56 8.16 9.40 50 9.10 16.00 21.00
Closed
Wide spray
Averagespray
1/2revolution
Narrowspray
1revolution
Open
1 2
4
3
