Berthoud MAXAIR 240 - Hydraulic Circuit of a MAXAIR Sprayer with APS 51 Pump - Manual Valves

36 320.055-B MAXAIR
HYDRAULIC CIRCUIT OF A MAXAIR SPRAYER WITH
APS 51 PUMP - MANUAL VALVES
ø 25
ø 16
ø 16
ø 35
ø 16
ø 16
ø 9
ø 9
ø 35
ø 35
ø 35
1
2
3
5
7
8
4
6
Nozzlefeed
1 - Handwashtank(18litres).
2 - Maintank(200/300/400/600litres).
3 - Drainvalve.
4 - Vannolter.
5 - APS51pump.
6 - Americanspraynozzle(optional).
7 - Rinsingtank(28litres)(optional).
8 - Distributionblock.
