32 320.055-B MAXAIR
CHECK THE OIL LEVEL OF THE TURBINE BEARING AND THE PUMP.
TURBINE BEARING(gure17)
 -Item1:Filling(withdrawthestopper).
 -Item2:Level (withdrawthestopper,theoilmustbelevelwiththeedgeofthehole).
Drainage:withdrawthestopper,withdrawthelocknutholdingthetubeandallowthepipestohang.
Oil for turbine bearing, MOBILUBE HD 80 W 90.
APS 51 PUMP (gure18)
 -Item1:Filling and level(withthepumpstopped,thelevelshouldreachthemarkonthevolumecompensator).
 -Item2:Drainage:unscrewthestopperandrotatetheshaftmanuallytodraintheoil.
SAE 30 oil for APS 51 PUMP
2-litre can, BERTHOUD reference 769.286.
GAMA 82 PUMP (gure19)
 -Thelevelmustreachthenotchlocatedonthegauge(1).
 -Item2:Completedrainageofthepump.
- Oil capacity for a GAMA 82 pump = 1.25 litre.
BERTHOUD HP 82 oil, 2-litre can, reference 779.026.
Only use this oil, otherwise the guarantee will not be considered as being respected.
PTO SHAFT
 -Foreachuse:GREASE+TUBES.
ELF EPEXA 2 or grease MOBILUX EP2.
- Important recommendations:
 -Itispreferabletocarryoutdrainagewhenthesprayerhasjustbeeninoperation.Theoilismoreuid
andowsmoreeasily.
 -Togreaseapointequippedwithalubricatingnipple,cleanthelatterrst.
- For components not equipped with lubricating nipples, remove the used grease.
- We recommend that you always use the same oil and grease.
- When lubricating the PTO shaft, take care to comply with the manufacturer’s instructions.
Change the oil during each spraying
campaign.
LUBRICATION AND GREASING
