22 320.055-B MAXAIR
FILL THE TANK
-Closethedrainoutletusingvalve(1)(gure6)locatedonthelefthandsideofthesprayer.
-Removethecoverandllthetank.
OPEN THE VANNOFILTRE VALVE (gure6)
-Pullpart(3)towardsyouthenturnaquarterofaturntoputitintoposition(4)
-Ifthecoverleaks,tightenthestarknob(5)slightly.
RINSING TANK
-Placethevalvehandle(2)atposition(b)(gure6).
ENGAGE THE TURBINE
-Toengagetheturbine,placelever(1)(gure7)onthenotch(2).
Caution:
The turbine engaging and release operations should be carried out with the clutch
of the POWER TAKE-OFF OF THE TRACTOR RELEASED.
CLUTCH THE POWER TAKE-OFF
-Simultaneouslyacceleratewithoutjerksinordertoprogressivelyobtainthenormalrotationspeed(540rpm).
ADJUST THE PRESSURE
- Manual version:
 -Handles(2)and(3)ofthedistributionblock(1)inposition(b)(horizontal)(gure8).
 -Adjustthepressurebyoperatingthewingnut(2)oftheregulator(1)(gure10):
  Turningclockwiseincreasesthepressure.
  Turningcounterclockwisereducesthepressure.
- Electric version:
 -Switchtheelectricunit(1)on(gure9),raisetheswitch(2).
 -Adjustthepressurebyoperatingthenut(2)oftheregulator(1)(gure10).
 Inbothcases,whenthedesiredpressureisreached(checkwithpressuregauge)lockthelocknut(3)ofthe
regulator(1)(gure10).
SPRAYING
- Manual version(gure8):
 -Handles(2)and(3)ofthedistributionblock(1)inposition(a)(vertical).
- Electric version(gure9):
 -Operatetheswitches(3).
 Inbothcases,engagetheclutchofthepowertake-offat540rpm.
RINSING THE SPRAYER WITH THE RINSING TANK
-Setthevalvehandle(2)atposition(a)(gure6).
- Manual version(gure8):
 -Handles(2)and(3)ofthedistributionblock(1)inposition(a)(vertical).
- Electric version(gure9):
 -Switches(2)and(3)inoperation.
 Inbothcases,engagetheclutchofthepowertake-offatthemaximum speed of 150 rpmsoasnottohave
areturntothetank.
OPERATION WITH THE GAMA 82 PUMP
