Appendix
43
R
E
A
D
ER
Feel better now!
Aer closing the side cover,
the air circulaon would flow
from the front to the back.
Without the side cover, it
will reduce the effect of
heat cooling.
Heat
Heat
The paern of heat releasing keeps drawing
air from the front to the back.
15cm
If the distance is too short, it will cause
heat-releasing failed.
Duplicator Tower
Wall
Wall
Duplicator Tower
Cooler
CoolerDrive 1
Drive 2
Drive 1
Drive 2
Heat Heat
Space
would
allow air
circulaon.
If no space, it
would fail to
release the
temperature.
Recycle
Components
Cause
Life
Short !!
Low Quality
Capacitor
Cause
Low
Capability
Sony
Sony
Sony
Sony
Pioneer
LG
It might cause problems of compability
or instablilty of copying speed if install
different brands of drivers.
Inside the chassis, the cooling fan can draw the air from the front to the back.
Without space between two drives, the cooling fan would fail to reduce heat
between drives.
Do & Don't
2
Be sure to keep distance between wall and the duplicator
at least 15cm to reduce heat.
