Section 5 Run Harness to Rear of Vehicle
Page 9
P9 - 54857 - Rev. A 0415
Installation Instructions - Trektop PRO Defrost Harness
© 2015 Bestop, Inc.
HardwareStep 1 Step 2
Failure to switch off the
defrost grid when the
vehicle key is turned
off will cause the
battery to drain.
Pull the carpet back just far enough to tuck
the harness underneath the body lip.
Zip tie the harness to the existing vehicle
harness running behind the carpet.
Step 1
Bring the connector end of the harness
out from under the body lip and plug it
into the existing vehicle harness.
Step 2
Wiring Harness “B”
POWER LOAD GROUND
1
2
To Next Page
