Section 1 Attach Wiring Harness to Vehicle Battery
Page 3
P3 - 54857 - Rev. A 0415
Installation Instructions - Trektop PRO Defrost Harness
© 2015 Bestop, Inc.
HardwareStep 1 Step 2
Attach Red terminal (+) on Wiring Harness
“A” to the positive terminal on the battery.
Attach the Black (-) on Wiring Harness “A” to
the negative terminal on the battery.
Step 1
Route the wiring harness across the firewall,
from the battery on the passenger side, to
the driver side, where the harness will pass
through the firewall.
Zip tie the wiring harness in place with 4 zip
ties. Zip tie the new wiring harness to the
existing vehicle harness.
Step 2
Wiring Harness “A”
Blk
Red
(+)
(-)
Red
(+)
Blk
(-)
