Section 2 Pass Wiring Harness Through Vehicle Firewall
Page 4
P4 - 54857 - Rev. A 0415
Installation Instructions - Trektop PRO Defrost Harness
© 2015 Bestop, Inc.
HardwareStep 1
Push the large connector end of the harness
through the rubber grommet in the firewall.
You may use a knife to make small cuts in
the grommet to allow the connector to fit
through the opening.
Step 1
Wiring Harness “A”
Blk
Red
(+)
(-)
