Section 5 Run Harness to Rear of Vehicle
Page 7
P7 - 54857 - Rev. A 0415
Installation Instructions - Trektop PRO Defrost Harness
© 2015 Bestop, Inc.
HardwareStep 1 Step 2
Using the trim removal tool,
remove the trim fasteners indicated.
Save the fasteners to be reused when
reinstalling the trim panel.
Step 1
After removing the trim fasteners,
push both pieces of trim back from
the door sill.
Tuck the wiring harness under the trim
panels, passing the connector around
the door pillar and underneath the trim
panel.
Step 2
Wiring Harness “B”
POWER LOAD GROUND
1
2
Trim
Removal Tool
1
2 43
