LaserSpeed 8000/9000 I/O Module Instruction Handbook
Setup
Part No. 93342 / Drawing No. 0921-01516 Page 36 of 84 Revision E (Dec 2013)
~A:MinElg Analog Output Minimum Elongation
~A:MinElg<CR> Read Setting
Response Format:
Analog MinElg <N><CR>
~A:MinElg=<N><CR> Set Value
Factory Default: 0 Minimum: -999999999 Maximum: 999999999
Where <N> is the elongation ratio at which the Velocity Analog Output reaches its
minimum value of 0V. This value can be a positive or negative value, or can be
zero.
Example: Sending the command ~A:MinElg=0<CR> will set the minimum
elongation ratio analog output to 0.0V when the elongation ratio is 0%. When the
elongation ratio is < 0%, the analog output will be limited to the minimum output
voltage of 0V.
~A / .A Analog Output Configuration
~A<CR> Read All Settings (with labels)
Example Response Format:
Analog
MaxVel 400000
MinVel 300000
MaxElg 1000
MinElg -500
Write Settings
~A<MaxVel>,<MinVel>,<MaxElg>,<MinElg><CR>
.A<CR> Read All Settings (without labels)
Example Response Format:
400000,300000,1000,-500<CR>
