LaserSpeed 8000/9000 I/O Module Instruction Handbook
Setup
Part No. 93342 / Drawing No. 0921-01516 Page 37 of 84 Revision E (Dec 2013)
Example: Write All Analog Settings
~A300000,100000,500,0
Sets the following:
Max velocity = 300
Min Velocity = 100
Max elongation ratio = 5%
Min elongation ratio = 0%
To calculate the velocity from the analog voltage, use the following formula.
To calculate the elongation ratio from the analog voltage, use the following
formula.
~B / .B IO Module Gauge RS-422 Communication Settings
~B<CR> Read Settings
Response Format:
Gauge_Serial
BaudRate <B>
StopBits <S>
DataBits <D>
Parity <P>
SyncMode <M>
ElongAvg <E>
