LaserSpeed 8000/9000 I/O Module Instruction Handbook
Setup
Part No. 93342 / Drawing No. 0921-01516 Page 41 of 84 Revision E (Dec 2013)
~D Test Mode
~D<CR> Read Settings
Response Format:
Test
TestMode <A>
TestNumber <B>
Testonoff <C>
~D<A><CR> Set Value
Factory Default: 0 Minimum: 0 Maximum: 2
Where <A> is the current test mode, and <B> and <C> are not used (should be
set to 0). <A> should be set to 0 for normal operation.
Mode <A>
Description
0
Normal Operation
1
Cycle Front Panel Lights
2
Simulate Normal Operation
~F:IP Ethernet IP Address
~F:IP<CR> Read Setting
Response Format:
ABEtherNet IP <IP><CR>
~F:IP=<IP><CR> Set Value
Factory Default: 192.168.1.111
Where <IP> is the IP address that the I/O Module will use for Ethernet
Communication.
This setting is only used when the I/O Module is equipped with an Ethernet
fieldbus card.
Example: To set the IP address to 192.10.1.100, send the command:
~F:IP=192.168.1.100<CR>
