LaserSpeed 8000/9000 I/O Module Instruction Handbook
Setup
Part No. 93342 / Drawing No. 0921-01516 Page 45 of 84 Revision E (Dec 2013)
Example Response Format:
192.168.1.111,255.255.255.0,0.0.0.0,4750,4751,192.168.1.100
Where <IP>, <NM>, <GW>, <UP>, <TP>, and <UI> are as follows:
Parameter
Description
<IP>
Ethernet IP Address
<NM>
Ethernet Netmask
<GW>
Ethernet Gateway Address
<UP>
Ethernet UDP Port
<TP>
Ethernet TCP Port
<UI>
Ethernet UDP Destination Address
This setting is only used when the I/O Module is equipped with an Ethernet
fieldbus card.
Example: To set the UDP Destination Address to 192.168.10.111, send the
command:
~F:UdpIP=192.168.1.111<CR>
~I:ReadyFlag Parallel Port Data Ready Output Polarity
~I:ReadyFlag<CR> Read Setting
Response Format:
ParallelPort ReadyFlag <N><CR>
~I:ReadyFlag=<N><CR> Set Value
Factory Default: 1 Minimum: 0 Maximum: 1
Where <N> indicates the polarity of the Data Ready output signal. This output
indicates when new data is available on the parallel output port.
