LaserSpeed 8000/9000 I/O Module Instruction Handbook
Operation
Part No. 93342 / Drawing No. 0921-01516 Page 77 of 84 Revision E (Dec 2013)
Ethernet Memory Structure
Bytes
Name
Equivalent LS9000/LS8000 command
1
Status/command
1st bit set LS setup, 2nd bit read LS put
in Fb
4
HoldVel;
B hold velocity
4
CalTrim;
C calibration trim
4
AnalogFull;
D analog full scale
4
MatPresDrop;
F Material present drop out time
4
MatPresValid;
G Material present Valid time
4
Hour;
H Hours since start r/o
4
PulseUnitHigh;
L pulse per unit length
4
AnaZero;
N analog zero value
4
PulsePerUnitLow;
P Pulse per unit length, low speed
4
Calibration;
TC reads calibration number
4
WalkThresh;
W walking threshold
4
MinFinalLength;
X minimum final length
2
Temperature;
I internal temperature r/o
1
FinalLengthMode;
TF Sets gauge to final length mode
1
Baud
J baud rate select
1
FilterLock;
E filter lock out
1
DipAvg
K Dip averaging
1
Unit
U units of measurement
1
ResetLength
R Reset length R/O
1
MatPresent
S Material present
1
ContTrans
TE sets gauge to continuous transmit
1
MatPresThres
M material present threshold
1
UserUpdate;
O User Update rate
16
GaugeType[16];
Z gauge type
