MAINTENANCE AND CHECKS
MANUTENZIONE E CONTROLLI
SMONTAGGIO SERBATOIO
CARBURANTE
Svitare la vite F di fissaggio del ser-
batoio al telaio, scollegare il tubo
del rubinetto carburante e togliere
il serbatoio sfilandolo, verso la parte
posteriore, dai pioli antivibranti pre-
senti sul telaio.
REMOVING THE FUEL TANK
Loosen screw F fixing the fuel tank to
the frame, disconnect the pipe from
the fuel cock and remove the tank
by pulling it towards the back of the
vehicle and off the anti-vibration
pegs on the frame.
F

Beta RR 125 series Specifications

General

Displacement	124.8 cc
Cooling System	Liquid cooled
Compression Ratio	12.5:1
Fuel System	Electronic fuel injection
Ignition	Electronic
Transmission	6-speed
Front Tire	90/90-21
Lubrication	Wet sump
Clutch	Wet multi-disc
Final Drive	Chain
Front Suspension	41 mm upside-down fork
Rear Suspension	Monoshock
Front Brake	260 mm disc
Rear Brake	220 mm disc
