Beta RR 250 User Manual

1
GENERAL INFORMATION
15
GB
SETTING THE PARAMETERS
General information:
Allowed settings:
• Km/h (kilometres per hour) or M/h (Miles per hour)
• Wheel size (rolling circumference) [mm]
• Clock format: 12-hour / 24-hour
• Current date
• Maintenance
TO ENTER THE PARAMETER SETTINGS MODE HOLD DOWN THE RIGHT AND LEFT
BUTTONS FOR APPROX. 3s.
THE WORD “Unit” WILL FLASH ON THE DISPLAY.
The operational logic is structured as follows:
• The instrument enters SETUP mode displaying the parameters according to the
sequence listed above.
• The instrument displays the parameter to be changed for a few seconds in fl ash
mode.
• If you wish to change the parameter displayed for those few seconds simply
edit the values by pressing the right and/or left buttons (according to the modes
listed below), otherwise wait a few seconds (approx. 5 s) to proceed to the next
parameter.
• When the parameter has been edited to the desired value, the instrument au-
tomatically moves onto the next setting, there is no need to press any button of
confi rmation.
• If you only wish to enter the setup mode to view the confi gured settings, simply wait
without pressing any buttons; the instrument will display all of the set parameters
and will then automatically go back to “Normal Mode”.
SETUP SEQUENCE
Select unit of measure
Wheel size
Clock format
Current date
Maintenance

Beta RR 250 Specifications

General

Displacement	249 cc
Transmission	6-speed
Front Suspension	Hydraulic USD fork with adjustable compression and rebound damping
Rear Suspension	Monoshock with adjustable compression and rebound damping
Front Brake	Single disc
Rear Brake	Single disc
Fuel Tank Capacity	9.5 liters
Seat Height	940 mm
Fuel System	Keihin PWK 36 carburetor
Front Tire	90/90-21
Rear Tire	140/80-18
Dry Weight	104 kg
Engine Type	2-stroke
Cooling System	Liquid
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Frame	Molybdenum steel
