Beta RR 250 User Manual

1
GENERAL INFORMATION
17
GB
SCREENS
Switching between 3 normal modes
All of the information that the instrument is capable of providing is displayed on one
of these 3 screens.
The instrument will stay on the set screen until a button is pressed to switch to another
screen.
TO SWITCH FROM ONE SCREEN TO ANOTHER, PRESS EITHER THE RIGHT OR
LEFT BUTTON BRIEFLY.
Screen 1:
• Speed • Distance 1 (DST) • Time
Screen 2:
• Speed • Distance 2 (DST2 ) • Time
Screen 3:
• Maximum speed (MAX) • Average speed (AVG)
• Accumulated running time (ART) • Odometer (ODO)
* Note: The maximum and average speeds are updated automatically when the
user accesses screen 3.
FEATURES
General information:
During normal use the instrument is in “Normal” mode.
Available modes:
• Sleep Mode
• Choose from 3 “Normal” screens
• Clear Distance 1 (DST1)
• Clear Distance 2 (DST2)
• Clear Maximum/Average Speed (MAX/AVG)
Sleep Mode:
If the instrument does not receive any input for 5 minutes (either from the movement
of the wheel or a button), it will go into “Sleep Mode”. In “Sleep Mode” only the
time appears on the screen.
To exit “Sleep Mode” all the instrument requires is an input, either from the movement
of the sensor or by pressing a button.

Beta RR 250 Specifications

General

Displacement	249 cc
Transmission	6-speed
Front Suspension	Hydraulic USD fork with adjustable compression and rebound damping
Rear Suspension	Monoshock with adjustable compression and rebound damping
Front Brake	Single disc
Rear Brake	Single disc
Fuel Tank Capacity	9.5 liters
Seat Height	940 mm
Fuel System	Keihin PWK 36 carburetor
Front Tire	90/90-21
Rear Tire	140/80-18
Dry Weight	104 kg
Engine Type	2-stroke
Cooling System	Liquid
Bore x Stroke	66.4 mm x 72 mm
Clutch	Wet multi-disc
Frame	Molybdenum steel
