19
PARTS LISTING
1 E89385 Sheathing 1
2 E89307 Traction Handle TK 530 1
3 E89425 Turned Adjuster #3 3
4 E89308 Lever Control Lateral B 1
5 E89309 Screw M6 x 16 1
6 1105303 Washer 6x12 3
7 1320031 Handwheel, 12x67 1
8 E89311 Ring Metal - Knurles 1
9 E89312 Sheath, Cable 1
10 E89063 Drive Cable BPS 28 1
11 E89427 Dowell #11 2
12 E89314 Screw Cable Fastening 2
13 E89078 Washer 8x17 7
14 E86853 Nyloc Hex Nut, M8 Zinc 3
15 E89315 Screw 8 x 25 3
16 2110025 Belt Tightening Lever 1
17 E89009 Spring 1
18 E89876 Screw 1
19 E89877 Roller, Belt 1
20 E89413 Bearing, 608 2RS 1
21 E89412 Inner Snap Ring 1
22 E89875 Spacer 1
23 2190011E Belt Tightener Bracket 1
24 E89175 Pin for rocker BPS28 2
25 E89176 Rocker bushing BPS28 2
26 2110017 Rocker 1
27 E87868 Self Locking Nut WS20/24 FS28/32 3
28 E89316 Screw 12 x 60 1
29 E89317 Non-Marking Caster 1
30 E89523 screw 6x20 BPS28 6
31 E89318 Screw M5 x 70 4
32 E89319 Nut M5 4
33 E89359 BPS Main Brush Assembly 1
34 E89383 Central brush shaft 1
35 E89199 Key 5-5-15 1
36 E87838 Brush Shaft Spacer BPS 28 2
37 E89081 Dowell 6x5 2
38 2260028 Bearing Support 2
39 E83277 Bearing, 6202 2RS 2
40 E89400 Outer Snap Ring 3
41 E89082 Outer Snap Ring 1
42 2230029 Brush Adjusting Fixing Pivot 1
43 E89079 Main Brush Adj. Bracket 1
44 2105001 Side Arm Felt Washer 2
45 E89482 Bearing, HK 1012 2
46 E86540 AS20 Screw M8x10 2
47 E89377 Spacer 1
48 E89321 Nut M8 2
49 E89322 Pulley, Brush Lateral 1
50 E89461 Gear Motor 1
51 E89334 Washer 1
52 E89387 Sheathing 1
53 E89386 Lift Cable 1
54 E87760 Pin 17x34 1
55 E89426 Clamp #55 1
56 E89324 Screw 8 x 22 1
57 E89076 Side brush lifting lever BPS 28 1
58 E89325 Washer 8 x 22 1
59 E89075 Ring for side brush BPS 28 1
60 E88498 Balls, Zinc 11/32" 6
61 E89084 Side Brush Toothed Ring BPS28 1
62 E89401 Key 3x3.7 1
63 2110012N Bushing 1
64 E86409 Bearing, 6005 2RS 2
65 E89085 Idle Toothed Ring BPS28 1
66 1105416 Outer Snap Ring 1
67 E89491 Traction Handle Casing 1
68 E86799 Spacer BPS28 2
69 E89326 Pulley, O27x15 Nylon 1
70 E89327 Belt, Dia. 8 x 1000 1
71 E89219 Washer 2
72 E89070 Side Brush Support 1
73 E86551 Side brush flange 1
74 E89328 Brush, Side 1
75 E89329 Pulley, O30x15 Nylon 1
76 E89330 Screw M6 x 10 3
77 E87788 Spacer 1
78 E89379 Bearing K1412 1
79 E87789 Spacer 1
80 E87790 Block Nut 1
81 E87935 Bushing 1
A. 2125100 Complete Brush Lifting Lever 1
B. E87770 Complete Movement Ring 1
C. E87771 Complete Idle Tooth Ring 1
D. 2310127 Complete Side Brush 1
E. E89424 Side Brush Sheathings and Cable (3-Piece Kit) 1
F. E89331 Carbon Brush 1
G. E87813 Bearing support BPS28 1
H. 2310291 Complete Pulley 1
I. 2310292 Complete Pulley 1
Item# Part # Description Qty. Item# Part # Description Qty.
