- 6 -

Having set the programming code, Codoor can be fitted to the door

in accordance with the accompanying installation instructions. Do

not forget to make a note of the programming code.

Programming code

NOTE:- The first 4 digits in the

programming code

must never be used

for any of the 9 access

codes

Code 1:

Code 2:

Code 3:

Code 4:

Code 5:

Code 6:

Code 7:

Code 8:

Code 9:

3 Installation kit

Make sure you have the following tools handy:

Cross-head screwdriver for door handle and cylinder ring screws.

Hack saw for trimming lever handle spindle. (See section Fitting to door).

The following parts are

supplied:

1 Codoor (batteries excluded).

4 extension sleeves for handle

nipples (2 M4 and 2 M5; use

only one pair).

1 reinforcing spring.

1 reinforcing spring holder.
