1.2.3 MCS 503 and MCS 501 Microphone Units for Table Mounting
To install the MCS 501 (delegate version) or MCS 503 (chairman version) microphone unit into a table, you need an appropriate
piece cut out of the table. Please refer to the appropriate template.
Then mount the microphone unit with the supplied fittings.
The MCS 501 delegate microphone unit has a microphone button to switch the microphone unit on and off or to register the
microphone unit in the system with the “Request-to-Speak” operating mode.
The MCS 503 chairman microphone unit has a microphone button, priority and clear button. For function please refer to
“1.2.1 Chairman Microphone MCS 513, MCS 523”.
1.2.4 MCS 553 and MCS 563 System Unit for Mounting under the Table
The MCS 553 and MCS 563 system units have been developed for mounting under the table. Depending on the number of the
connected buttons the system units work as chairman unit (3 buttons: microphone, priority, clear) or delegate unit (1 button: micro-
phone). Using the MCS Editor software, the system unit is configured as chairman or delegate. Please refer also to chapter “6. MCS
System Configuration via MCS Editor”.
Mounting
There are holes needed in the table for the microphone and the buttons. Each system unit is mounted with 4 screws under the table.
Please refer to the appropriate template.
Connection
The system units are fitted with a fixed connecting cable and a connecting socket. The connection is according to the single cable
principle, i.e. the 1st system unit is connected to the control unit, the 2nd system unit to the 1st system unit and so on.
The MCS 553 is fitted with a detachable gooseneck microphone and a terminal board for the connection of buttons. On request a
terminal board for a loudspeaker can be also fitted.
The MCS 563 is fitted with a terminal board for the connection of microphone, LED ring and buttons. On request a terminal board for a
loudspeaker can be also fitted.
1.2.1 Chairman Microphone Unit MCS 513, MCS 523
The chairman microphone unit is equipped with 3 buttons.
Priority button
The function of the priority button depends on how it has been configured in the MCS 50 discussion control unit. The chairman can
either mute or clear all activated delegate microphone units.
Microphone button
The microphone button allows the chairman to switch on his microphone unit independingly from the number of open microphones
at any time.
Clear button
Pressing the clear button, the chairman clears all activated microphone units. In the Request-to-Talk mode all registered microphone
units are also cleared.
1.2.2 Delegate Microphone Unit MCS 511, MCS 521
The delegate microphone unit is equipped with one button, the microphone button. Using this button, the delegates can
switch their microphone unit on and off or register in the Request-to-Talk mode.
