27 System Configuration Commands
v - Stream status flags (8 bits)
bit 7
6
5
4
3
2
1
bit 0
N.U.
ResChair
StreamAct/Deact
bit 7-2 N.U.: not in use, unimplemented bit
bit 1 ResChair: reserved for chairman
1 = reserved
0 = not reserved
>> This bit indicates whether the corresponding stream is reserved for the
chairman or not. If it is reserved, it cannot be allocated to another
device.
bit 0 StreamAct/Deact: stream activated/deactivated
1 = stream activated
0 = stream deactivated
>> This bit indicates whether the stream is activated or not.
>> CU-REPLY message on S 0 command <<
Communication direction
CU -> Controller
Syntax
Description
StrX muad m n
Stream allocation status message
Parameters
Description
StrX
Stream C/D/E/F named as StrC/StrD/StrE/StrF
muad
Source MU ID
[range: 0x000001 0xFFFFFF]
m
Stream information flags (8 bits)
n
Allocation mode flags (8 bits)
m - Stream information flags (8 bits)
bit 7
6
5
4
3
2
1
bit 0
N.U.
MuteStat
ResChair
reserved
reserved
StrRiAll/Free
StrLeAll/Free
StrAc/Deac
bit 7 N.U.: not in use, unimplemented bit
