28 System Configuration Commands
bit 6 MuteStat: Mute Status
1 = Stream muted
0 = Stream unmuted
bit 5 ResChair: Stream reserved for chairman
1 = Stream reserved
0 = Stream not reserved
>> This bit indicates whether the corresponding stream is reserved for the
chairman or not. If it is reserved, it cannot be allocated.
bit 4-3 reserved
bit 2 StrRiAll/Free: Stream right: allocated or free
1 = Stream allocated
0 = Stream free
bit 1 StrLeAll/Free: Stream left: allocated or free
1 = Stream allocated
0 = Stream free
bit 0 StrAc/Deac: Stream activated/deactivated
1 = Stream activated
0 = Stream activated
>> This bit indicates whether the stream is activated or not.
n - Allocation mode flags (8 bits)
bit 7 N.U.: not in use, unimplemented bit
bit 6-4 MUZone: represents the zone in which the MU is used
>> These zones are used, for example, to sound different locations, which
are then discreetly assigned to the zones. When the zoning function is
enabled, each output is assigned to a specific zone. In each zone,
several microphone units are mixed together according to their division.
For example, a zone can also be assigned to the headphone output of
the microphone units.
