29 System Configuration Commands
bit 3 LeftRight: right flag, if MU is double delegate
1 = left flag
0 = right flag
>> This bit is 0 if it is a Double Delegate; the property of the Double Delegate
to have two microphones and to be able to activate them at the same
time is thus expressed.
bit 2-0 AllocationMode
>> The AllocationMode refers to the assignment of MUs to a specific func-
tionality. This functionality is important when assigning audio streams,
since a stream is permanently reserved for a chairman.
Examples
000
Single Delegate (SDel)
001
Double Delegate (DDelL, DDelR)
010
Chairman (Chrm)
011
reserved
Display allocation table
& Set stream status
Transmit:
S 0<CR>
This command shows the allocation table, which does
include all important audio stream data.
Receive:
<CR><LF>
StrC 000000 00 00<CR><LF>
StrD 000000 01 00<CR><LF>
StrE 000000 01 00<CR><LF>
StrF 000000 01 00<CR><LF>
>
Stream C is activated and not reserved for chairman.
Transmit:
S C 3<CR>
This command activates stream C and reserves it for
chairman.
Receive:
<CR><LF>
>
Transmit:
S C<CR>
Shows stream information of stream C.
Receive:
<CR><LF>
StrC 000000 21 00<CR><LF>
>
The third group of digits with 0x21 now shows the settings
made in the last step.
