BFT ARGO BT A 35 - Radio Channel Control Configuration; Radio Menu

ENGLISH
Logic Denition Default
Cross
out
setting
used
Optional extras
EXPI1
Conguration
of EXPI1 input
on input-output
expansion
board.
1-2
2
0 Input congured as Start E command.
1 Input congured as Start I command.
2 Input congured as Open command.
3 Input congured as Close command.
4 Input congured as Ped command.
5 Input congured as Timer command.
6 Input congured as Timer Pedestrian command.
7 Input congured as Phot (photocell) safety.
8 Input congured as Phot op safety (photocell active during opening only).
9 Input congured as Phot cl safety (photocell active during closing only).
10 Input congured as Bar safety (safety edge).
11
Input congured as safety Bar OP, safety edge with inversion active only while opening, if while closing the mo-
vement stops.
12
Input congured as safety Bar CL, safety edge with inversion active only while closing, if while opening the mo-
vement stops.
13 Input congured as Phot test safety, tested photocell.
14 Input congured as Phot op test safety, tested photocell active only while opening.
15 Input congured as Phot cl test safety, tested photocell active only while closing.
16 Input congured as Bar safety, tested safety edge.
17
Input congured as safety Bar OP test, safety edge with inversion active only while opening, if while closing the
movement stops.
18
Input congured as safety Bar CL test, safety edge with inversion active only while closing, if while opening the
movement stops.
EXPI2
Conguration
of EXPI2 input
on input-output
expansion
board.
1-3
3
0 Input congured as Start E command.
1 Input congured as Start I command.
2 Input congured as Open command.
3 Input congured as Close command.
4 Input congured as Ped command.
5 Input congured as Timer command.
6 Input congured as Timer Pedestrian command.
EXPO1
Congura-
tion of EXPO2
output
on input-output
expansion
board
4-5
13
0 Output congured as monostable Radio Channel.
1 Output congured as SCA (gate open light).
2 Output congured as Courtesy Light command.
3 Not used
4 Not used
5 Not used
6 Not used
7 Not used
8 Not used
EXPO2
Congura-
tion of EXPO2
output
on input-output
expansion
board
6-7
16
9 Output congured as Maintenance.
10 Not used
11 Not used
12 Not used
13 Output congured as Gate Status
14 Output congured as Bistable Radio Channel
15 Output congured as timed Radio Channel
16 Output congured as open gate Status
17 Output congured as Output 1 PROGRAMMABLE IN HEIGHT
18 Output congured as Output 2 PROGRAMMABLE IN HEIGHT.
(**) Active only if the output is congured as Monostable Radio Channel, Courtesy Light, Zone Light, Stair Light, Bistable Radio Channel or Timed Radio Channel.
AUX output conguration
Aux logic= 0 - MONOSTABLE RADIO CHANNEL output.
Contact stays closed for 1s when radio channel is activated.
Aux logic= 1 - SCA GATE OPEN LIGHToutput.
Contact stays closed during opening and with leaf open, intermittent during closing, open with leaf closed.
Aux logic= 2 - COURTESY LIGHT command output.
Contact stays on for 90 seconds after the last operation.
Aux logic= 3 – Not used
Aux logic= 4 – Not used
Aux logic= 5 – Not used
Aux logic= 6 – Not used
Aux logic= 7 – Not used
Aux logic= 8 – Not used
Aux logic= 9 - MAINTENANCE output.
Contact stays closed once the value set for the Maintenance parameter is reached, to report that maintenance is required.
Aux logic= 10 – Not used
Aux Logic= 11 – Not used
Aux Logic= 12 – Not used
Aux logics= 13 - GATE STATUS output
Contact stays closed while gate is closed.
AUX logics= 14 - BISTABLE RADIO CHANNEL output
The contact changes status (open-closed) when the radio channel is activated
AUX logics= 15 - TIMED RADIO CHANNEL output
The contact remains closed for a programmable length of time when the radio channel is activated (output time)
If, during this time, the button is pressed again, counting starts all over again.
Aux logic= 16 - GATE OPEN ALARM output.
Contact stays closed when the gate is open.
Logic Aux=17 – Output 1 PROGRAMMABLE IN HEIGHT.
The contact closes when the door exceeds the percentage opening set in parameter “Out Prog 1”
Logic Aux=18 – Output 2 PROGRAMMABLE IN HEIGHT.
The contact closes when the door exceeds the percentage opening set in parameter “Out Prog 2”
Command input conguration
IC logic= 0 - Input congured as Start E. Operation according to STEP-BY-STEP
OV. logic. External start for trac light control.
IC logic= 1 - Input congured as Start I. Operation according to STEP-BY-STEP
OV. logic. Internal start for trac light control.
