Art. 62625
Engine Timing Tool Kit for VAG 1.4 / 1.6 FSI / TSI
GENERAL INFORMATIONEN
This Tool Set includes all important tools for checking and adjusting the engine timing on VAG 1.4
and 1.6 L FSI / TSI engines with timing chain. Engine codes AXU, BAG, BKG, BLF, BLN, BLP, BLG,
BLY
TOOLS
Camshaft Locking Tool T10171
Dial Gauge Adapter (matching dial gauge BGS 1938-1) T10170
Crankshaft Locking Bolt T10340
Chain Tensioner Locking Pin T40011
SAFETY ADVICE
Be careful when working on hot engines – risk of burn!
• Be careful when working on running engines. Loose clothes, tools and
other things can be caught up in revolving parts which may lead to serious
injuries.
• Remove the ignition key before repair so that the engine will not start
unintentionally.
• This manual is just brief information and will not replace a workshop
manual. Always consult specific service literature for information about
torques, assemblies and disassemblies etc.
• After any successful maintenance and before starting the engine, you
should rotate the engine for two turns manually to check the new control
time.
