REV. B | 10/09/20208
10. Raise canopy
Raise canopy to mounting bracket, aligning the four holes on the canopy with the holes
on the bracket. Secure canopy to mounting bracket with the painted screws (Fig. 10).
Make sure all wires and the safety cable are tucked in the canopy.
Fig. 10
Canopy
Canopy Screw
Building Structure
Loop safety cable around building structure, and then secure it with the shackle (Fig.
9.3). Acceptable building structures include a wooden beam or a metal mounting brace
secured between two beams. In some cases it may be necessary to install additional
structural material to provide attachment points.
Fig. 9.3
Safety Cable
Shackle
To Next Page
