REV. B | 10/09/20204
5. Install mounting bracket
Disconnect power to fan location before installing mounting bracket.
WARNING: Mount only to an outlet box marked acceptable for fan support.
Secure mounting bracket to mounting structure with suitable hardware (not supplied)
(Fig. 5). Outlet box shown. Your mounting structure may di er from the illustration.
Power supply omitted from mounting bracket illustration for clarity.
Fig. 5
Suitable Mounting Hardware
6. Hang fan
Raise fan to mounting bracket. Align rib in mounting bracket with slot in mounting ball,
position mounting ball, and let fan hang freely (Fig. 6).
Gently twist downrod to ensure it is properly seated and will not move during fan
operation.
Fig. 6
Mounting Ball
Mounting Bracket
Mounting Bracket
To Next Page
