BIG ASS FANS es6 User Manual

© 2020 DELTA T LLC Ι ALL RIGHTS RESERVED. 1
INSTALLATION
1. Install downrod and wiring harness
Align holes on downrod with holes on motor bracket. Secure downrod with the M6 x
32mm bolt and M6 nut (Fig. 1.1).
Fig. 1.1
M6 x 32 mm Bolt
M6 Nut
Connect wiring harness from downrod to receptacle from motor unit (Fig. 1.2).
Fig. 1.2
Wiring Harness

BIG ASS FANS es6 Specifications

General

Brand	BIG ASS FANS
Model	es6
Category	Fan
Language	English
