☑ Prepare Concrete Ceiling (if applicable)
Drill three Ø 6 mm holes in the pattern shown. The hole depth should not exceed
40mm. Remove any dust from the holes. Insert three anchor bolts (not supplied)
into the holes. Strike the heads of the anchor bolts with a hammer, ensuring the
bolt sleeves are fl ush with the ceiling surface. Position the mounting bracket on the
anchor bolts. Ensure all three anchor bolts are fully tightened to expand and lock
the anchors.
If required by local building and safety codes, install an anchor hook (not supplied) for
the safety cable. Drill an Ø 8 mm hole for the anchor hook. The hole depth should not
exceed 50 mm. Remove any dust from the hole, and then insert the anchor hook and
fully tighten.
Ø 6 mm
45 mm 43 mm
112 mm
50 mm max
40 mm max
