Hooklift trailer 8-12
Frame (hollow section) 200x100x6
Wheel dimension 19/45-17; 480/45-17; 400/60-15,5
Requisite tractor hydraulics 1 break outlet; 2 double action
Electric system 12V
Oil volume *** 8
Trailer weight (kg)* 2200-2400 kg
Trailelength (mm)* Min 5790 – Max 6400
Width across wheels (mm)* 2100
Total weight (kg) 12150
Max load including container (kg) 10000
Max load during container exchange (kg) 8000
Load on towing eye(kg)** 1500-2000
Max tipping capacity (kg) 10000
Max working pressure (Mpa) 17,0
Hooklift trailer 10-14
Frame (hollow section) 200x100x6
Wheel dimension 435/50R-19,5; 500/50-17
Requisite tractor hydraulics 1 break outlet; 2 doube action
Electric system 12V
Oil volume*** 8
Trailer weight (kg)* 2300-2500 kg
Trailer length (mm)* Min 5790- Max 6400
Width across wheels (mm)* 2300
Total weight (kg) 14300
Max load including container (kg) 12000
Max load during container exchange (kg) 10000
Load on towing eye (kg) ** 1600-2300
Max tipping capacity (kg) 12000
Max working pressure (MPa) 22,0
