Hooklift trailer 12-15 G2
Frame (hollow section) 200x100x6
Wheel dimension 435/50-19,5; 500/50-17
Requisite tractor hydraulics 1 brake outlet, 4 double action
Electric system 12V
Oil volume*** 27
Trailer weight (kg)* 2700-2900
Trailer length (mm)* Min 5790- Max 6400
Width across wheels (mm)* 2300
Total weight (kg) 14500
Max load including container (kg) 12000
Max load during container exchange (kg) 12000
Load on towing eye (kg)** 1600-2300
Max tipping capacity (kg) 12000
Max working pressure (MPa) 21,0
Hooklift trailer 14-17
Frame (hollow section) 200x100x6
Wheel dimension 435/50-19,5; 500/50-17
Requisite tractor hydraulics
1 brake outlet, Electric control valve,
preassure and free return
Electric system 12V
Oil volume*** 10
Trailer weight (kg)* 2800-3100 kg
Trailer length (mm)* Min 5790- Max 6400
Width across wheels (mm)* 2400
Total weight (kg) 14500
Max load including container (kg) 14000
Max load during container exchange (kg) 14000
Load on towing eye (kg)** 1600-2500
Max tipping capacity (kg) 14000
Max working pressure (MPa) 22,0
*Depending about equipment of the trailer
** Depending in the position of the container and equipment of the trailer. Check your permitted towing eye vertical load value as marked to the
towing eye.
*** Minimum available oil volume, with full system (L)
