BigDog Alpha - 36;42 Inch Deck Belt Routing; 52 Inch Deck Belt Routing

REV B 6-8 119293
NOTE: The following notes are the same for the different decks shown.
1. There is no tension adjustment of this belt
2. Route belt as shown.
36”/42" Deck Belt Routing
52" Deck Belt Routing
Figure 6-22
Figure 6-23
