Binary B-660-MTRX-4X4 User Manual

10
7. IR IN
Connect to the third-party IR control device.
5. 
 
The B-660-MTRX-4x4 occupies 1U space when installed in a standard 19” equipment rack.
Steps to Install the Matrix in an Equipment Rack:
1. Aach the Mounng Ears to the enclosure using the screws provided in the package
separately.
2. The Mounng Ears are aached to the enclosure as shown.
3. Repeat steps 1-2 for the other side of the unit.
4. Mount and ax the unit in the rack with the mounng screws.

Binary B-660-MTRX-4X4 Specifications

General

Brand	Binary
Model	B-660-MTRX-4X4
Category	Matrix Switcher
Language	English
