9. 

Input/Output Port
4 x HDMI IN, 4 x HDMI OUT
4 x AUDIO OUT (3.5mm analog L/R audio
out),
1 x RS-232, 1 x Network, 1 x IR IN,
1 x AC 100-240V 50/60Hz
Input/Output Signal Type
HDMI with 4K@60Hz 4:4:4, HDR, HLG &
Dolby Vision, HDCP 2.2
Input/Output Resoluon Supported
VESA:
800x600
8
, 1024x768
8
, 1280x768
8
,
1280x800
8
, 1280x960
8
, 1280x1024
8
,
1360x768
8
, 1366x768
8
, 1440x900
8
,
1600x900
8
, 1600x1200
8
, 1680x1050
8
,
1920x1200
8
SMPTE:
720x576P
6
, 1280x720P
6,7,8
,
1920x1080P
2,5,6,7,8
, 3840x2160
2,3,5,6,8
,
4096x2160
2,3,5,6,8
1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz,
4 = at 29.97 Hz, 5 = at 30 Hz, 6 = at 50 Hz,
7 = at 59.94 Hz, 8 = 60 Hz, 9 = 75 Hz
Audio Format
HDMI IN/OUT: Fully supports audio formats
in HDMI 2.0 specicaon, including PCM
2.0/5.1/7.1, Dolby TrueHD™, Dolby Atmos™,
DTS-HD Master Audio™ and DTS:X™
L&R Analog AUDIO OUT: Stereo
Maximum Data Rate HDMI IN & HDMI OUT: 18Gbps
Control Method
IR, RS-232, CEC, Network Control (Telnet &
Web UI)

Operang Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (-4°F to 140°F)
Humidity 10% to 90%, non-condensing
ESD Protecon
Human-body Model:
±15kV (Air-gap discharge)
Power Supply AC 100-240V 50/60Hz
Power Consumpon (Max) 26W
Device Dimension
(W x H x D)
440mm x 43.5mm x 300mm/17.32” x 1.71” x
11.81” (without mounng brackets)
Product Weight 3.24kg/7.14lb
Rack Space Required 1U
