1. 
The B-660-MTRX-4x4 is a 4K HDR 4x4 HDMI Matrix Switcher and allows up to four Ultra
High Denion 4K HDR or 1080p HD inputs to be independently distributed to four Ultra
HD displays. Analog audio outputs are also included for 2ch PCM audio de-embedded from
each HDMI output allowing for audio to be distributed separately from each HDMI output.
This matrix is controllable via IR, RS-232 and LAN using the built in Web UI. An API is available
separately for RS-232 and LAN control.
This matrix was designed to be an Ultra HD A/V distribuon soluon ideal for a variety of
applicaons that include Home Theater, Oces, Schools, Conference Rooms, Hotels, etc. All
this contained in a compact chassis that occupies only 1U of rack mount space.
2. 
4 HDMI inputs and 4 HDMI outputs
Inputs and outputs support video resoluons up to 4K@60Hz 4:4:4 8bit and HDCP 2.2
Supports 4K HDR, HLG & Dolby Vision
Fast switching between mulple video sources
Supports L/R analog audio de-embedding outputs from each HDMI output (2ch PCM Audio
only)
Supports IR, RS-232 and LAN (Telnet API & Web UI) control opons
Supports API command control through RS-232 and Telnet connecon
3. 
1 x B-660-MTRX-4x4 Matrix
1 x AC Power Cord with US Pins
1 x IR Remote
2 x Mounng Brackets (with Screws)
1 x Installaon Manual
