Binder B 28 - B 28 Technical Data

B / E 07/2017 page 26/40
9.4 B 28 technical data
Exterior dimensions
Width, net
mm / inch
580 / 22.83
Height, gross (incl. feet)
mm / inch
402 / 15.83
Depth
mm / inch
425 / 16.73
Depth, gross (incl. door handle)
mm / inch
85 / 3.35
Wall clearance, rear (minimum)
mm / inch
100 / 3.94
Wall clearance, side (minimum)
mm / inch
160 / 6.30
Doors
Number of doors
1
Number of inner glass doors
1
Interior dimensions
Width
mm / inch
400 / 15.75
Height
mm / inch
280 / 11.02
Depth
mm / inch
250 / 9.84
Interior volume
l / cu.ft.
28 / 0.99
Racks
Quantity of racks (regular)
2
Quantity of racks (max.)
4
Maximum load per rack
Kg / lbs
10 / 22
Permitted total load
Kg / lbs
25 / 55
Weight
Weight (empty)
Kg / lbs
23 / 51
Temperature data
Temperature range, by 5 °C above ambient up to
°C
70 / 158
Temperature fluctuation at 37 °C / 98.6 °F
± K
1
Electrical data for B 28 230V type (model versions B028-230V, B028-230V-T)
IP system of protection acc. to EN 60529
IP
20
Nominal voltage (+/-10 %)
at 50 Hz power frequency
V
230
at 60 Hz power frequency
V
230
Current type
1N~
Nominal power
kW
0.25
Power plug
shock proof plug
Installation category acc. to IEC 61010-1
II
Pollution degree acc. to IEC 61010-1
2
Chamber fuse 5x20 mm / 250V / time-lag (T)
A
6,3 external
Different electrical data for B 28 120V type constructed for the USA and Canada
(model version B028-120V)
Nominal voltage (+/-10 %) at 60 Hz power frequency
V
115
Nominal power
kW
0.20
Power plug
NEMA
5-15P
All technical data is specified for unloaded chambers with standard equipment at an ambient temperature
of +22 °C ± 3 °C / 71.6 °F ± 5.4 °F and a power supply voltage fluctuation of +/-10. Technical data is
determined in accordance to BINDER Factory Standard Part 1:2015 following DIN 12880:2007.
All indications are average values, typical for chambers produced in series. We reserve the right
to change technical specifications at any time.
