2.1 Chamber overview
Figure 3: Chamber overview, closed chamber
Figure 4: Chamber overview, open chamber with glass door (BD-S / BD-S-UL)
(1) Triangular instrument panel with R-S controller
(2) Outer door
(2a) Outer door handle
(3) Exhaust air outlet
(3a) Exhaust air flap
(4) Glass door (BD-S / BD-S-UL)
(4a) Glass door handle (BD-S / BD-S-UL)
(5) Rack
(5a) Rack support
