12.4 FED technical data
Unit size
53
115
240
400
720
Exterior dimensions
Width
mm
inch
634
24.96
834
32.83
1034
40.71
1234
48.58
1234
48.58
Height (incl. feet/castors)
mm
inch
617
24.29
702
27.64
822
32.36
1022
40.24
1528
60.16
Depth
mm
inch
575
22.64
645
25.39
745
29.33
765
30.12
865
34.06
Depth incl. door handle, and
exhaust duct
mm
inch
90
3.54
90
3.54
90
3.54
90
3.54
90
3.54
Wall clearance rear
mm
inch
100
3.94
100
3.94
100
3.94
100
3.94
100
3.94
Wall clearance side
mm
inch
160
6.30
160
6.30
160
6.30
160
6.30
160
6.30
Exhaust duct, outer diameter
mm
inch
52
2.05
52
2.05
52
2.05
52
2.05
52
2.05
Steam space volume
l
cu.ft.
77
2.72
158
5.58
308
10.88
498
17.60
869
30.71
Number of door(s)
1
1
2
2
2
Interior dimensions
Width
mm
inch
400
15.75
600
23.62
800
31.50
1000
39.37
1000
39.37
Height
mm
inch
400
15.75
480
18.90
600
23.62
800
31.50
1200
47.24
Depth
mm
inch
330
12.99
400
15.75
500
19.69
500
19.69
600
23.62
Interior volume
l
cu.ft.
53
1.9
115
4.1
240
8.6
400
14.3
720
25.7
Number of racks, regular / max.
2/4
2/6
2/7
2/10
2/15
Load per rack
Kg
lbs
15
33
20
44
30
66
35
77
45
99
Permitted total load
Kg
lbs
40
88
50
110
70
155
90
199
120
265
Weight (empty)
Kg
lbs
44
97
62
137
96
212
145
320
195
430
Temperature data
Temperature range, 5 °C / 9 °F above
ambient up to
°C
°F
300
572
300
572
300
572
300
572
300
572
Temperature fluctuation at 150 °C /
302 °F
≤± K
0.3 0.3 0.3 0.3 0.3
Temperature
uniformity
(variation) 1)
at 70 °C / 158 °F
± K
0.8
0.7
0.8
1
1
at 150 °C / 302 °F
± K
2
1.8
2
2.5
2
at 300 °C / 572 °F
± K
3.7
3.9
4.3
4.8
5.5
Heating up time
2)
to 70 °C / 158 °F
min
6
7
12
18
25
to 150 °C / 302 °F
min
24
30
27
35
39
to 250 °C / 482 °F
min
45
49
50
60
65
Recovery time
after door was
opened for 30 sec
2)
at 70 °C / 158 °F
min
2
2
2
2
2
at 150 °C / 302 °F
min
5
8
10
17
20
at 300 °C / 572 °F
min
10
15
16
21
24
