FED (E2) 12/2014 page 9/55
Prohibition signs
Do NOT touch
Do NOT spray with
water
Information to be observed in order to ensure optimum function of the product.
1.2.4 Word message panel structure
Type / cause of hazard.
Possible consequences.
∅ Instruction how to avoid the hazard: prohibition
 Instruction how to avoid the hazard: mandatory action
Observe all other notes and information not necessarily emphasized in the same way, in order to avoid
disruptions that could result in direct or indirect injury or property damage.
1.3 Localization / position of safety labels on the unit
The following labels are located on the unit:
Pictograms (Warning signs)
Service label
Hot surface
• Outer unit door
• On unit rear next to the exhaust
duct
Read operating manual
• UL units: on outer unit door
Figure 1: Position of labels on the unit front
