33
POWER
INPUT
Figure 24 Top of the CU
Treatment Head Port
(Marked with man symbol)
Any Treatment Head may be plugged into port. Plugs and sockets
are polarized; therefore they must be correctly orientated before
they can lock. Align the mark on the plug with the mark on the
socket.
Power Input
Input for the power adapter. Do not use any other adapter except
the one provided by Meditech or your local distributor. Use of
any other power sources will damage this unit.
USB
This port is used when it is required that the system be connected
with a computer.
DO NOT OPERATE THE UNIT WHILE CONNECTED
TO A COMPUTER.
