4
BITS Power Supply Kit (UK): BIT-A001
(Only Included with UK Installations)
Description Illustration (Reference Only) Quantity
UK Power Strip 1
UK Power Cord 1
Note: Verify that all components have been received. Do not start the installation process if any of the listed
components are missing. For technical support contact Bioness Client Relations Department at (800) 211-9136,
Option 3 or your Bioness Sales Representative.
Tools Needed for Installation
The list below includes items needed to install the BITS. The tools are not provided with the system.
• 14mm Wrench
• 14mm Socket Driver (optional)
• Phillips Screw Driver
• Scissors
• Safety Gloves
• Box Cutter with Safety Guard
Unpacking and Setting Up the Hardware Kit
1. The BITS Hardware Kit is a large package that is delivered on top of a wooden palette. The package consists of a
palette with ramp, layered cardboard, foam inserts, shipping straps, and plastic shipping wrap. See Figure 1.
2. Remove all plastic shipping wrap by cutting it from the top with a box cutter.
3. Cut all green shipping straps. Start with the straps located above the wooden ramp, see Figure 1.
4. Lower the wooden palette ramp.
BITS Power Supply Kit (UK): BIT-A001
(Only Included with UK Installations)
Description Illustration (Reference Only) Quantity
EU Power Strip 1
EU Power Cord 1
