Biostar G41D3C Setup Manual

G41D3C
5
CHAPTER 2: HARDWARE INSTALLATION
2.1 I
NSTALLING CENTRAL PROCESSING UNIT (CPU)
Special Notice:
Remove Pin Cap before installation, and make good preservation
for future use. When the CPU is removed, cover the Pin Cap on the
empty socket to ensure pin legs won’t be damaged.
Pin-Cap
Step 1: Pull the socket locking lever out from the socket and then raise
the lever up to a 90-degree angle.

Biostar G41D3C Specifications

General

Form Factor	Micro ATX
Chipset	Intel G41
Socket	LGA 775
Memory Type	DDR3
Memory Slots	2
Maximum Memory	8 GB
Integrated Graphics	Intel GMA X4500
Storage Interface	4 x SATA 3Gb/s
Video Outputs	1 x VGA
Audio	Realtek ALC662 6-Channel HD Audio
IDE Ports	1 x IDE
USB Ports	8 x USB 2.0
LAN	Realtek RTL8111E
Expansion Slots	1 x PCIe x16, 1 x PCIe x1, 2 x PCI
