챕터 2: 하드웨어 설치 | 9
H81MHV3 3.0
4단계: 엄지와 검지로 지시방향과 같이 CPU를 잡아 주십시오. 홈에 맞추어 CPU를
아래로놓아 주십시오.
5단계: CPU를단단히 고정하고레버를아래로잠근후설치를완료합니다.
»
LGA1150 소켓용 CPU를 올르게 설했는지 확인하여 주십시오.
»
CPU는 오직 한 방향으로만 설치가 가능합. CPU가 손되지 않록 과한 힘을 가하
십시오.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Biostar H81MHV3 3.0 and is the answer not in the manual?

Biostar H81MHV3 3.0 Specifications

General IconGeneral
Processor socketLGA 1150 (Socket H3)
Processor manufacturerIntel
Compatible processor seriesIntel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium
Maximum number of SMP processors1
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR3-SDRAM
Maximum internal memory16 GB
Supported memory clock speeds1066, 1333, 1600 MHz
DirectX version11.1
Parallel processing technology support-
Supported storage drive interfacesSATA II, SATA III
Wi-FiNo
Ethernet interface typeGigabit Ethernet
Audio chipRealtek ALC887
Component forPC
Motherboard chipsetIntel® H81
Audio output channels5.1 channels
Motherboard form factormicro ATX
Windows operating systems supportedWindows 10, Windows 7, Windows 8, Windows 8.1
Headphone outputs3
DVI-D ports quantity0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cables includedSATA
Weight and Dimensions IconWeight and Dimensions
Depth190 mm
Width170 mm
