10 | 챕터 2: 하드웨어 설치
2.2 CPU 쿨러 설치
1단계: 설치된 CPU 위에 CPU 쿨러를놓고 네 개의잠금장치가 메인보드의 CPU 소켓
주변 홀에 정확히 위치하는지확인합니다. 방향에 맞춰 조립하고 CPU 팬 커넥터에 팬
케이블과 가장 가깝게 위치하도록하십시오.
2단계: 대각선 방향으로 한 번에 2개의 잠금장치를 아래로 밀어 제 자리에 CPU 쿨러가
장착되도록 합니다. 각잠금장치가정상적으로잠기면 딸깍하는 소리가 납니다.
»
하다면, CPU 쿨를 설기 전 CPU에 효과적인 열를 돕는 써멀 그리스 등을
바르시기랍니다.
»
CPU 팬 커를 반드시 연결해야 합니.
»
합한 설를 위해, CPU 쿨러 설치 설명서를 부디 참해 주십오.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Biostar H81MHV3 3.0 and is the answer not in the manual?

Biostar H81MHV3 3.0 Specifications

General IconGeneral
Processor socketLGA 1150 (Socket H3)
Processor manufacturerIntel
Compatible processor seriesIntel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium
Maximum number of SMP processors1
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR3-SDRAM
Maximum internal memory16 GB
Supported memory clock speeds1066, 1333, 1600 MHz
DirectX version11.1
Parallel processing technology support-
Supported storage drive interfacesSATA II, SATA III
Wi-FiNo
Ethernet interface typeGigabit Ethernet
Audio chipRealtek ALC887
Component forPC
Motherboard chipsetIntel® H81
Audio output channels5.1 channels
Motherboard form factormicro ATX
Windows operating systems supportedWindows 10, Windows 7, Windows 8, Windows 8.1
Headphone outputs3
DVI-D ports quantity0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cables includedSATA
Weight and Dimensions IconWeight and Dimensions
Depth190 mm
Width170 mm
